Adopted tunable diode laser absorption spectroscopy (TDLAS) technology, self-developed compact, long-range multiple reflection gas absorption cell; exclusive wavelength modulation and normalized data processing algorithms. It can measure CO2 and CH4 simultaneously, and the measuring substances can be expanded. Based on 5G/NB-IoT to achieve wireless data transmission, it is suitable for new energy digitization, low-altitude economy, urban security, intelligent agriculture and other quantitative data acquisition scenarios.
Carry-Away, Suitcase-Type Analyzer
Domesticated Core Components
Exclusive Wavelength Modulation and Demodulation Technology
Millisecond Spectral Measurement
性能指标 | CO2 | CH4 |
量程 | 0 ~ 2000 ppm | 0 ~ 500 ppm |
精度 | < 3 ppm,1 ppm ( 5 s,5 min ) | < 20 ppb,5 ppb ( 5 s,5 min ) |
响应时间 | 0.1 s ~ 10 s | |
漂移 | < 5 ppm ( 24 hr ) | < 30 ppb ( 24 hr ) |
数据传输 | USB,5G/NB-IoT,RS485 / RS232 可选 | |
功率 | < 80 W | |
工作环境 | 10 ~ 40 ℃ ;< 99% 相对湿度(非凝结状态) | |
结构尺寸 | 560×350×230 mm(长×宽×高) |
